3 Roller Hydraulic Plate Rolling Machine

About 3 Roller Hydraulic Plate Rolling Machine

ADVANTAGES Heavy duty reinforced welded steel frame. Solid Rolls of EN 8/9 with material TC Epicyclic Planetary Gearbox for higher torque Spherical roller bearings on all 3 roll shafts. Bottom rolls hydraulically driven independently. Easy Conical Bending Push button control of forward/reverse. Digital Display of roll position HMI color display STANDARD ACCESSORIES Solid Rolls of EN 8/9 with material TC Planetary Gearbox for higher torque Spherical roller bearings on all 3 roll shafts. Sophisticated Hydraulc Power Pack Movable Operating Panel Desk Push button Hydraulic swing arm for finished part removal. OPTIONAL ACCESSORIES Hardened & Ground Rolls Variable Speed of Rotation Material Feeding Table Side Support for large diameter shells Hydraulic Top Support for large diameter shells. Auto Ejection System for removing bending parts Oil Air Cooling System Automatic Lubrication System Plate Feeding Support Table Plate feeding table can be made by roller assembly, auto self-alignment and automatic plate feeding. It reduces your cycle time and gives fast production and removes the alignment errors. Hydraulic Top Support for Large Diameter Shells While making the large diameter shells the shape is deformed by the self weight. Hydraulic Top Support holds the shell at the top and can be adjusted at the required height. Hydraulic Side Support for Large Diameter Shells While making the large diameter the shape is deformed by the self weight. Hydraulic Side Support holds the shell at both the sides and can be adjusted at the required height.
